Filter Screen

Product Name

Separate Pump Screen (200 mesh)

Tatsuno Pump Screen (100 mesh)

Tatsuno Pump Screen (200 mesh)

Combined Pump Flat Screen (200)

Combined Pump Screen (200 mesh)

Technical Specifications

Material

Stainless Steel

Stainless Steel

Stainless Steel

Stainless Steel

Stainless Steel

Filtration Rating

75 microns

150 microns

75 microns

75 microns

75 microns

Media

Hydraulic Oil, Gasoline, Diesel, etc.

Product Introduction: This metal dispenser screen is a washable, reusable coarse-filter element, usually installed at the pump suction inlet or in the piping. It traps large fuel contaminants to protect downstream equipment.

Product Features
1. Durable woven stainless-steel mesh provides oil and corrosion resistance, mechanical strength and long life.
2. Reusable: remove and clean clogged screens with diesel or a cleaning agent, dry and reinstall. Fewer replacements reduce maintenance costs.
3. As an upstream coarse filter, it traps metal chips, grit and other large particles to prevent abnormal pump wear and seizure and support continuous operation.
4. Simple construction allows easy cleaning without specialist tools and rapid restoration of performance.
5. Open mesh and low initial pressure loss support normal pump suction efficiency.
